Ring Main Unit :
   SPECIFICATION TYPE GR1

¡¡
¡¡



¡¡


SPECIFICATION

  • Rated Voltage : 12kV

  • Impulse Withstand Voltage : 95kVp

  • Frequency : 50Hz

  • Normal Current, Ring Switch : 630A

  • CB : 630A

  • Short-circuit Breaking Current, CB : 20kA

  • Short-time Withstand Current : 20kA, 3 Seconds

  • Short-circuit Making Current, Ring Switch : 50kAp

  • CB : 50kAp

  • Earthing Switch : 50kAp

COMPLIANCE WITH

  • IEC56:1987, BS5311:1988  Tee-off Circuit Breaker

  • IEC3+6:1983, BS5463:1977  Ring Switch

  • IEC129:1984, BS5253:1975  Earthing Switch

  • Temperature Range  +40¡É to -25¡É


¡¡
